Dell Vostro 3480 - Touchpad; Removing the Touch Pad Assembly

Next steps
1 Replace the speakers
2 Replace the battery
3 Replace the base cover
4 Replace the SD memory card
5 Follow the procedure in after working inside your computer
Touchpad
Removing the touch pad assembly
Prerequisites
1 Follow the procedure in before working inside your computer
2 Remove the SD memory card
3 Remove the base cover
4 Remove the battery
Steps
1 Remove the two (M2x2) screws that secure the touch pad bracket to the palmrest and keyboard assembly [1].
2 Lift the touch pad bracket o the palm rest and keyboard assembly [2].
Removing and installing components
49
