Delta Electronics DUP-B Series User Manual

Chapter 3 Creating and Editing Screens
3.14.3.3 Data Transfer
There are five commands for data transfer, including MOV, BMOV, FILL, FILLASC and
FMOV.
 MOV (Transfer Data)
Equation
Var1 = Var2
Explanation
Transfer data from Var2 to Var1. No data change within Var2 after executing MOV
command.
Remark
 The calculation result can be stored as WORD and DWORD.
 Var1 can be internal memory only. Var2 can be internal memory or constant.
Example
$0 = 0
The data within the internal memory address $0 is assigned to the constant 0 (this is
an operation of unsigned 16-bit data).
$1 = 99999 (Signed DW)
The data within the internal memory address $1 is assigned to the constant 99999
(this is an operation of signed 32-bit data).
3-328 Revision May, 2010
