Chapter 5 System Menu
5.3 Up/Download Menu
There are two kinds of communication modes when connecting HMI to PC through COM
serial port.
1. Standard Mode
2. Bypass Mode
Cross Reference of Function Keys and Screen Icons
LEFT
RIGHT
CLICK
BACK
1.
Standard Mode
When this mode is selected, COM serial port is connected to PC directly and the
data upload and download is performed through Screed Editor software
program. There are COM1 and COM2 two communication ports for selection.
