Page #16 background imageLoading...
Page #16 background image
Ethernet Communication Module IFD9506
DVP-PLC Operation Manual
14
BR4 High byte
B7
B6~B4
B3
B2
B1
B0
138
10001011
139
Enable Enable Serial Master Modbus RTU
10001100
140
Enable Enable Serial Slave Delta configuration ASCII
10001101
141
Enable Enable Serial Slave Delta configuration RTU
10001110
142
Enable Enable Serial Slave Modbus ASCII
10001111
143
Enable Enable Serial Slave Modbus RTU
BR5: Baud Rate
Explanations:
BR5 Low byte
Description
The baud rate is defined, which is the same as that set by the rotary switch
Content
Baud rate
Data
Baud rate
Data
Baud rate
110
0x06
2,400
0x0B
57,600
150
0x07
4,800
0x0C
115,200
0x03 300 0x08 9,600
0x04 600 0x09 19,200
0x05 1,200 0x0A 38,400
BR5 High byte
Content
Same as Low byte
BR6: Node Address
Explanations:
For filling in or reading the Modbus address. The address will be displayed in the message display after being
set.
BR11: Communication Time-out (ms)
Explanations:
For setting the communication time-out. Default = 5,000ms. For example, if you wish to set the communication
time-out to 7 seconds manually, write 7000 into BR11.
BR12: Communication Delay Time (ms)
Explanations:
For setting the minimum interval time between every Modbus communication datum. Default = 0ms. For
example, if you wish to set the communication delay time to 100ms manually, write 100 into BR12.
BR13: TCP Connection Idle Time (s)
