Ethernet Communication Module IFD9506
DVP-PLC Operation Manual
45
Field
Description
Number of connections (to server, max.= 8)
The number of connections to remote TCP Server made
by IFD9506 at present
Count of disconnections (to server)
Total number of failures of connection to remote TCP
server
Ethernet/IP Information
Number of TCP connections for EtherNet/IP
(max.= 8)
The number of TCP connections for EIP communication
Number of EtherNet/IP IO connections (implicit
message)
The number of implicit-message connections which are
in use
Serial Information
RS232 Frame Received
The total number of packets received by RS232 port
RS232 Frame Sent
The total number of packets transmitted by RS232 port
RS232 Frame Received (Byte)
The total length of packets received by RS232 port
RS232 Frame Sent (Byte)
The total length of packets transmitted by RS232 port
RS232 Last Frame Received (Byte)
The length of the last packet received by RS232 port
RS232 Last Frame Sent (Byte)
The length of the last packet transmitted by RS232 port
RS485 Frame Received
The total number of packets received by RS485 port
RS485 Frame Sent
The total number of packets transmitted by RS485 port
RS485 Frame Received (Byte)
The total length of packets received by RS485 port
RS485 Frame Sent (Byte)
The total length of packets transmitted by RS485 port
RS485 Last Frame Received (Byte)
The length of the last packet received by RS485 port
RS485 Last Frame Sent (Byte)
The length of the last packet transmitted by RS485 port
9.3.2 Protocol Diagnostic
The Protocol diagnostic page displays the diagnostic data related to the communication protocol.
