Delta Electronics IFD9506 User Manual

Ethernet Communication Module IFD9506
DVP-PLC Operation Manual
13
Ethernet Communication Module: IFD9506
BR
No.
Attribute Register name Explanation Default Latched
Symbol “R” refers to read only; “R/W” refers to read and write.
3.4 Explanation of Basic Registers (BR)
BR0: Model Name
Explanations:
The model code of IFD9506 is 0x0200.
BR1: Firmware Version
Explanations:
The firmware version of IFD9506 is displayed in hex, e.g. 0x0100 indicates version V1.00.
BR4: Communication Format
Explanations:
BR4 Low byte
Description
The data format is defined, which is the same as that set by the rotary switch
Content
Data
Format
Data
Format
Data
Format
Data
Format
0x00
7-N-1
0x03
8-O-1
0x08
7-N-2
0x0B
8-O-2
0x01
8-N-1
0x06
7-E-1
0x09
8-N-2
0x0E
7-E-2
0x02
7-O-1
0x07
8-E-1
0x0A
7-O-2
0x0F
8-E-2
BR4 High byte
B7
B6~B4
B3
B2
B1
B0
Description
RS-485 User
Define
0: Disable
1: Enable
Reserved
RS-232
User
Define
0: Disable
1: Enable
Mode setting
0: Serial Master
Ethernet Server
1: Serial Slave
Ethernet Client
RS-232 function
0: Delta configuration
1: Modbus
Mode
0: ASCII
1: RTU
Content
00000000（0）
Disable
Disable
Serial Master
Delta configuration
ASCII
00000001（1）
Disable
Disable
Serial Master
Delta configuration
RTU
00000010（2
）
Disable Disable Serial Master Modbus ASCII
00000011（3
）
Disable Disable Serial Master Modbus RTU
00000100（4
）
Disable Disable Serial Slave Delta configuration ASCII
00000101
（
5）
Disable
Disable
Serial Slave
Delta configuration
RTU
00000110
（
6）
Disable
Disable
Serial Slave
Modbus
ASCII
00000111
（
7）
Disable
Disable
Serial Slave
Modbus
RTU
00001000
（
8）
Disable
Enable
Serial Master
Delta configuration
ASCII
10000111
（
135
）
Enable Disable Serial Slave Modbus RTU
10001000
（136）
Enable Enable Serial Master Delta configuration ASCII
10001001
（137）
Enable Enable Serial Master Delta configuration RTU
10001010
Enable Enable Serial Master Modbus ASCII
