Ethernet Communication Module IFD9506
DVP-PLC Operation Manual
6
 Terminal block (COM2)
Interface Feed-through terminal 10PIN
Transmission method RS-485
Transmission distance 1,200m
Transmission speed
110, 150, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
bps
Communication
protocol
Modbus, User Define
 Environment
Noise immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line: ±2KV, Digital Input:
±2KV,
Communication I/O: ±2KV
RS (IEC 61131-2, IEC 61000-4-3): 80MHz~1GHz, 10V/m. 1.4GHz ~
2.0GHz, 10V/m
Conducted Susceptibility Test (EN61000-4-6, IEC61131-2 9.10): 150kHz
~ 80MHz, 3V/m
Surge Test (Biwave IEC61132-2, IEC61000-4-5):
Power line 0.5KV DM, Ethernet 0.5KV CM, RS-485 0.5KV CM
Operation 0°C ~ 55 °C (temperature), 50% ~ 95% (humidity), pollution degree 2
Storage -25°C ~ 70°C (temperature), 5% ~ 95% (humidity)
Vibration/shock immunity
Standard: IEC 61131-2, IEC 68-2-6 (TEST Fc)/IEC61131-2 & IEC 68-2-
27
(TEST Ea)
Certificates IEC 61131-2, UL508
 Electrical specification
Power supply voltage 24VDC (-15% ~ 20%) supplied by the feed-through terminal block
Power consumption 3W
Insulation voltage 500V
Weight 140g
