Delta Electronics NH Plus Series User Manual

3
Η
General View
3-20
3-5 Technical Specification
Capacity 80KVA/64KW 120KVA/96KW
Rating Voltage V
220/380, 230/400, 240/415
(3ӥʳ 4W+Earth)
Voltage Regulation % -25 ~ +20
Input Current Harmonic Distortion
(Full Load)
% < 5
PFC (Full Load) > 0.99
Frequency Hz 50 / 60
Input
Frequency Tolerance Hz 45 ~ 65
Output Voltage V 220/380, 230/400, 240/415 (3ӥʳ 4W+Earth)
Output Frequency Hz 50 / 60
Total Harmonic (Linear Load) % Љ3
Voltage
Regulation
Static % 1
Dynamic % 7 (10% ~ 90% Linear Load)
Frequency
Regulation
Interior Oscillator Hz 0.05
Synchronized % 5
Output
Overload Љ125%: 10minutes ; Љ150%: 1minute
Battery Backup Intermittent Audible
Warning
UPS Abnormal Continuous
LED UPS status: Normal, Bypass, Backup and Fault
Display
LCD
Input/Output, Bypass, Inverter, Frequency, Loading and Battery voltage, current,
UPS abnormal message and intelligent self diagnosis
Monitor
Monitor up to 31 PCs, Graphically display records and historical data and Fault records
retrieved
Remote
Control Remote control the Inverter and alarm, setup password and auto-dial warning
Standard RS232, Dry Contact Output
Interface
Optional
SNMP card, Modbus card, Relay I/O control card, Environmental sensor box, SNMP+5
Ports Hub
Parallel Redundancy Yes (1+1 for two UPSs of the same capacity only!)
EPO Standard (Local and Remote)
SRAM Event Log Yes (500 records)
Parameter Configuration Yes
Hot Standby Installation Feasible
Battery Temperature Compensation Optional
Others
Battery Start Standard
Normal % 94
Efficiency
ECO % 97
Transfer Time ms 0
Temperature °C 0Д40
Humidity (Non Condensed) % 90
Noise (One Meter) dBA 70
Dimension Width mm 520 520
Depth mm 910 975
Height mm 1165 1695
Overall
Weight Kg 259 379
