Modulon NH Plus Series 3-19
Send the e-mail and SNMP trap to notify users.
Provides InsightPower Client software to protect public operating systems.
Provides InsightPower Manager to monitor all of the UPS information in the network.
Provides InsightPower EzSetting software to easily configure for the first time and
upgrade firmware.
Technical Specification
Network Connection RJ-45
Temperature 0~40°C
Humidity 10~80% (Relative)
Input Power 12V DC
Power Consumption 4.5 Watt. (Maximum)
Dimension (W x D x H) 65x143 x 28 mm
Weight 320g
Dip Switch Mode
SW1 SW2 Mode
ON ON Configuration
ON OFF
Environmental
Sensor
OFF ON Pass Through Mode
OFF OFF Normal
