Installation and Wiring

4-8

4-5-3 Connecting External Battery Cabinet

Connect corresponding terminals (

+, N, –) between UPS and external battery cabinet.

Fig. 4-3 Wiring of External Battery Cabinet

UPS Battery Cabinet
