Ethernet & Sequencer Programming SM15K
13 / 44 DELTA ELEKTRONIKA B.V. rev. Aug. 2019
5.4.2 Calibrate Gain Measure Current
To calibrate the gain of the current measurement:
Syntax : CALIbrate:CURrent:MEAsure:GAIn<sp><NR2><term>
To read the calibration settings:
Syntax : CALIbrate:CURrent:MEAsure:GAIn?<term>
5.4.3 Calibrate Gain Measure Voltage
To calibrate the gain of the voltage measurement:
Syntax : CALIbrate:VOLtage:MEAsure:GAIn<sp><NR2><term>
To read the calibration settings:
Syntax : CALIbrate:VOLtage:MEAsure:GAIn?<term>
5.4.4 Calibrate Offset Measure Current
To calibrate the offset of the current measurement:
Syntax : CALIbrate:CURrent:MEAsure:OFFset<sp><NR2><term>
To read the calibration settings:
Syntax : CALIbrate:CURrent:MEAsure:OFFset?<term>
5.4.5 Calibrate Offset Measure Voltage
To calibrate the offset of the voltage measurement:
Syntax : CALIbrate:VOLtage:MEAsure:OFFset<sp><NR2><term>
To read the calibration settings:
Syntax : CALIbrate:VOLtage:MEAsure:OFFset?<term>
Note: Range Offset : About 1/30 of the maximum output voltage/current, Range Gain : 0.9 to 1.1
5.5 Power Sink
5.5.1 Introduction
The following commands are available to check the presence of an optional Power Sink, to read the
settings and to change them.
5.5.2 RSD
To set up the Power Sink that it reacts on RSD:
Syntax: SYSTem:POWersink<sp>rsd,<boolean><term>
To check the setting:
Syntax: SYSTem:POWersink<sp>rsd?<term> 1 = reacts on RSD
5.5.3 Interlock
To set up the Power Sink that it reacts on Interlock:
Syntax: SYSTem:POWersink<sp>interlock,<boolean><term>
To check the setting:
Syntax: SYSTem:POWersink<sp>interlock?<term> 1 = reacts on Interlock
5.5.4 Output On/Off
To set up the Power Sink that it reacts on Output On/Off:
Syntax: SYSTem:POWersink<sp>output,<boolean><term>
To check the setting:
Syntax: SYSTem:POWersink<sp>output?<term> 1 = reacts on Output On/Off
5.6 System Subsystem
5.6.1 Remote Shut Down (RSD)
Syntax : SYSTem:RSD[:STAtus]<sp><boolean><term>
Boolean = 0, 1, OFF (Unlocked), ON (Locked)
To read the last setting:
Syntax : SYSTem:RSD[:STAtus]?<term>
5.6.2 Limits
To set the limits of the voltage:
Syntax : SYSTem:LIMits:VOLtage<sp><NR2>,<boolean><term> Off = disabled, On = enabled
To read the last setting:
Syntax : SYSTem:LIMits:VOLtage?
