5.2.4 Control Registers
*If you use HWCONFIG to set values in CRs, once the set value is downloaded, the values can be retained in
the module; however if you use TO instruction to write data into CRs, the values CANNOT be retained, after
power failure or after transition of the CPU from STOP to RUN.
Note: The attribute of the CR must be W (write) to use TO instruction.
CR# Name Description
Atr. Defaults
0
Format Setup
0: integer format
1: floating point format
R 0
1
Input channel 1 mode setup
0: closed
1: -10 V to +10 V (default)
2: 0–10 V
3: -5 to +5 V
4: 0–5 V
5: 1–5 V
6: 0–20 mA
7: 4–20 mA
8: -20 mA to +20 mA
R/W 1
2
Input channel 2 mode setup
3
Input channel 3 mode setup
4
Input channel 4 mode setup
5
Input channel 1 offset
Range: -32768 to +32767
R/W 0
6
Input channel 2 offset
7
Input channel 3 offset
8
Input channel 4 offset
9
Input channel 1 gain
Range: -32768 to +32767
R/W 1000
10
Input channel 2 gain
11
Input channel 3 gain
12
Input channel 4 gain
13
Input channel 1 average
times
Range: 1–100 R/W 10
14
Input channel 2 average
times
15
Input channel 3 average
times
16
Input channel 4 average
times
17
Input channel 1 filter
R/W 1
