Delta AS02PU-A - Specifications

Chapter 10 Function Cards
10-45
10
10.2.9.3 Specifications
 System Specifications
Item
Specification
General
Device type
Slave
Topology
Star and linear topologies are supported.
IP Settings
When installed on AS300 PLC CPU, you can use
HWCONFIG from ISPSoft for editing
Availability
AS300 Series PLC
Web
Max. connection number
8
Functions
View device information
Account management
AS-FOPC02 firmware update
 OPC-UA Specifications
Item
Specification
General
Device type
Server
OPC-UA Server
Max. connection number
2
Max. tag number
64
Security mode
(1) None
(2) Sign
(3) Sign and Encrypt
Security policy
(1) Basic128Rsa15
(2) Basic256
(3) Basic256Sha256
Authentication
(1) Anonymous
(2) User name/Password
Transport protocol / encoding
opc.tcp / binary
Supported profiles
UA v1.03 Nano Embedded Device Server Profile
 EtherNet/IP Specifications
Item
Specification
General
Device type
Adapter
CIP Network I/O
Connection
CIP connection number
8
TCP connection number
8 (Servers)
Requested Packet Interval
(RPI)
1 ms~1000ms
Max. Transmission Speed
10,000 pps
Max. data length/per
transmission
200 bytes
CIP Network
Explicit Message
Class 3 (Connected Type)
Total 8 (Servers)
(for both class 3 and UCMM connection types)
UCMM
(Non-Connected Type, only
uses TCP connections)
CIP Objects
Identity Object (16#01)
Message Router Object (16#02)
Assembly Object (16#04)
Connection Manager Object (16#06)
Port Object (16#F4)
TCP/IP Interface Object (16#F5)
Ethernet Link Object (16#F6)
Not supporting self-defined objects
