Chapter 8 Load Cell Module AS02LC
8- 5
8_
8.2.4 Control Registers
*If you use HWCONFIG to set values in CRs, once the set value is downloaded, the values can be retained in
the module; however if you use TO instruction to write data into CRs, the values CANNOT be retained, after
power failure or after transition of the CPU from STOP to RUN.
Note: The attribute of the CR must be W (write) to use TO instruction.
CR# Name Description
Att.
Default
0
Display options for
CH1
0: disabled
1: gross weight
2: net weight
3: raw data
R/W
1
1 Eigenvalue for CH1
0: 1 mV/V
1: 2 mV/V
2: 4 mV/V
3: 6 mV/V
4: 20 mV/V
5: 40 mV/V
6: 80 mV/V
R/W
1
2 Sampling cycle for CH1
0: 2.5ms
1: 10ms
2: 16ms
3: 20ms
4: 50ms
5: 60ms
6: 100ms
7: 200ms
8: 400ms
R/W
4
3
Weight measured times in a
stability range for CH1
Range: K1–K500
R/W
5
4
Stability range for CH1
Floating-point format
Range: 0–100000
R/W
10
5
6 Maximum weight for CH1
Floating-point format
Maximum measuring weight; when the
R/W
100,000
