AS Series Module Manual
9- 2
_9
9.1 Introduction
Thank you for using the AS00SCM-A, a serial communication module. To ensure that your AS00SCM-A is installed
and operated correctly, read this manual carefully before using the module.
The AS00SCM-A is a serial communication module, supporting AS series communication extension modules as well
as the remote modules (RTU) and the following communication cards:
 Serial communication cards: AS-F232, AS-F422, and AS-F485 support Modbus and UD Link (user-defined
format).
 CANopen communication card AS-FCOPM supports CANopen DS301.
 Ethernet communication card AS-FEN02 supports EtherNet/IP Adapter.
 Ethernet communication card AS-FPEN02 supports PROFINET. Refer to Chapter 10 of AS Module Manual for
more information.
AS00SCMVe
rsion
and
its
supporting
functions
COM.
(serial communication
extension module mode)
RTU
(remote module mode)
MODBUS
UD Link
CANopen
DS301
(Slave)
AS Remote
Communication,
Delta Special Driver
& AS Remote Mode
CANopen
DS301
(Slave)
EtherNet/IP
Adapter
PROFINET
Device
Card
AS-F232
AS-F485
AS-F422
AS-FCOPM
AS-FCOPM
AF-FEN02
(V1.02 or
later)
AS-
FPFN02
(V2.00 or
later
Card Slot Card 1 / Card 2 Card 2 Card 2
V1.00 V - - - - -
V2.00 V V V - - -
V2.02 V V V V V -
V2.06 V V V V V V
When AS00SCM-A is used as a remote module, its right side supports AS Series IO modules.
 For firmware version V2.06 or later: when AS00SCM-A works with AS-FCOPM and acts as a remote module,
its right side supports AS04SIL-A. Refer to Chapter 13 of AS Module Manual for more information.
 For firmware version V2.06 or later: when AS00SCM-A works with AS-FPFN02 and acts as a remote module,
its right side supports all AS Series module types, except AS02LC-A.
When AS00SCM-A acts as a serial communication extension module, it should work with AS PLC CPU for
configuration. Use ISPSoft to configure AS00SCM-A. You can download ISPSoft V3.09 or later versions from Delta’s
official website. If you use UD Link, configure it through SCMSoft, which is embedded in DCISoft. Download DCISoft
V1.20 or later from Delta’s official website. You can set up the EtherNet/IP via EIP Builder. Download EIP Builder
V1.07 or later from Delta’s official website.
