Delta ASDA-B2-F Series User Manual

ASDA-B2-F Inspection and Model Explanation
September, 2015 1-5
1
ECMA Series Servo Motor 0
ECMA-C10602ES
      
 Product Name ECM: Electronic Commutation Motor
 Motor Type A: AC Servo Motor
 Name of the Series
Motor Frame Size
Rated Power Output
Type of Shaft Diameter and Oil Seal
 Shaft Diameter
Standard S
Specific
3 42 mm
7 14 mm
Rated Voltage and Rated Speed
Code Spec.
C 220 V / 3,000 rpm
E 220 V / 2,000 rpm
F 220 V / 1,500 rpm
G 220 V / 1,000 rpm
Encoder Type
Code Spec.
1 Incremental type, 20-bit
2 Incremental type, 17-bit
3 2500 ppr
M Magnet type, 13-bit
code Spec. code Spec.
04 40 mm 10 100 mm
06 60 mm 13 130 mm
08 80 mm 18 180 mm
09 86 mm - -
code Spec. code Spec. code Spec.
01 100 W 05 500 W 10 1.0 kW
02 200 W 06 600 W 15 1.5 kW
03 300 W 07 700 W 20 2.0 kW
04 400 W 09 900 W 30 3.0 kW
w/o Brake,
w/o Oil Seal
with Brake, w/o
Oil Seal
w/o Brake, with
Oil Seal
With Brake,
with Oil Seal
Round Shaft
(with fixed screw holes)
- - C D
Keyway E F - -
Keyway
(with fixed screw holes)
P Q R S
