Parameters ASDA-B2-F
7-50 September, 2015
7
P3-xx Communication Parameters
P3-00● ADR Address Setting
ddress: 0300H
0301H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 01
Control
Mode:
ALL
Unit: - Range: 0x01 ~ 0x7F
Format: HEX Data Size: 16-bit
Settings:
The communication address setting is divided into Y and X (hexadecimal):
- 0 0 Y X
Range
－ －
0 ~ 7 0 ~ F
When using RS-232 to communicate, one servo drive can only set one address. Duplicate address
setting will cause abnormal communication.
This address represents the absolute address of the servo drive in the communication network
which is applicable to RS-232 and DMCNET bus.
When the communication address setting of MODBUS is set to 0xFF, the servo drive will
automatically reply and receive data regardless of the address. However, P3-00 cannot be set to
0xFF.
P3-01 BRT Transmission Speed
ddress: 0302H
0303H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 3203
Control
Mode:
ALL
Unit: Bps Range: 0x000 ~ 0x3405
Format: HEX Data Size: 16-bit
Settings:
The setting of transmission speed is divided into Z, Y and X (hexadecimal):
- 0 Z Y X
Communication Port
－
DMCNET
－
RS-232
Range 0 0 ~ 4 0 0 ~ 5
Definition of setting value X
0: 4800 1: 9600 2: 19200
3: 38400 4: 57600 5: 115200
Definition of setting value Z
0: 125 Kbit/s 1: 250 Kbit/s 2: 500 Kbit/s
3: 750 Kbit/s 4: 1.0 Mbit/s -
Note:
If this parameter is set via DMCNET, only Z can be set and the others remain.
P3-02 PTL Communication Protocol
ddress: 0304H
0305H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 6
Control
Mode:
ALL
Unit: Bps Range: 0 ~ 8
Format: HEX Data Size: 16-bit
Settings:
The definition of the setting value is as the followings:
0: 7, N, 2(MODBUS, ASCII) 1: 7, E, 1(MODBUS, ASCII) 2: 7, O, 1(MODBUS, ASCII)
3: 8, N, 2(MODBUS, ASCII) 4: 8, E, 1(MODBUS, ASCII) 5: 8, O, 1(MODBUS, ASCII)
