Delta ASDA-B2-F Series User Manual

Wiring ASDA-B2-F
3-20 September, 2015
3
3.3.4 DI and DO Signal Specified by Users
If the default setting of DI/DO does not fulfill the requirement for the application, users can
manually define the DI/DO signal. The signal function of DI 1 ~ 5, and DO1 ~ 2 is determined by
parameter P2-10 ~ P2-14 and parameter P2-18 ~ P2-19 respectively. Please refer to the
following table. Enter DI or DO code in the corresponding parameter to set up DI/DO.
Signal Name Pin No
Corresponding
Parameter
Signal Name Pin No
Corresponding
Parameter
Standard
DI
DI1- CN1-1 P2-10
Standard
DO
DO1+ CN1-12
P2-18
DI2- CN1-2 P2-11 DO1- CN1-13
DI3- CN1-3 P2-12 DO2+ CN1-14
P2-19
DI4- CN1-4 P2-13 DO2- CN1-15
DI5- CN1-5 P2-14 - - -
