Delta ASDA-B2-F Series User Manual

ASDA-B2-F Wiring
September, 2015 3-21
3
3.4 CN2 Connector
CN2 encoder connector can be connected in two ways:
Encoder Connector
快速接頭
軍規接頭
Connect to the motor
CN2 Connector
Connect to the servo drive
CN2 on drive side
The terminal block of the connector and pin number are as follows:
(A) CN2 Connector
View from
this side
12345
6789
Rear view of the terminal block
(B) Encoder Connector
Quick Connector
View from
this side
1
2
3
4
5
6
7
8
9
123
4
56
789
View from
this side
Military Connector
A
E
B
D
C
HF
G
L
K
J
M
N
P
RS
T
