Delta ASDA-B2-F Series User Manual

ASDA-B2-F Trial Operation and Tuning
September, 2015 5-11
5
5.5.1 Flowchart of Tuning Procedure
If the estimation of inertia ratio is
incorrect, it cannot obtain the best
performance of tuning.
Resonance can be suppressed
by P2-23 and P2-24.
New model?
Trial run without load
is OK.
Exit the control of the host controller.
Use the servo drive to perform trial
run and estimate the inertia ratio*
Manual mode Semi-auto mode Auto mode
Connect to the host controller. Pay
attention to the wiring of CN1. Perform
trial run by P4-07 and P4-09.
Use the selected gain tuning mode
to enhance the performance.
OK
Yes
No
Note: The value of inertia ratio is used for rotary motors.
Figure 5-1 Tuning procedure
