ASDA-B2-F Installation
September, 2015 2-5
2
2.5 Specification of Circuit Breaker and Fuse
Caution: Please use the fuse and circuit breaker that is recognized by UL/CSA.
Servo Drive Model Circuit Breaker Fuse (Class T)
Operation Mode General General
ASD-B2-0121-F 5A 5A
ASD-B2-0221-F 5A 6A
ASD-B2-0421-F 10A 10A
ASD-B2-0721-F 10A 20A
ASD-B2-1021-F 15A 25A
ASD-B2-1521-F 20A 40A
ASD-B2-2023-F 30A 50A
ASD-B2-3023-F 30A 70A
Note：
If the servo drive equips with earth leakage circuit breaker for avoiding electric leakage, please choose the
current sensitivity which is over 200 mA and can continue up to 0.1 seconds.
2.6 EMI Filter Selection
Item Power Servo Drive Model
Recommended EMI Filter
Foot Print
1PH 3PH
1 100 W ASD-B2-0121-F RF007S21AA RF022M43AA N
2 200 W ASD-B2-0221-F RF007S21AA RF022M43AA N
3 400 W ASD-B2-0421-F RF007S21AA RF022M43AA N
4 750 W ASD-B2-0721-F RF007S21AA RF022M43AA N
5 1000 W ASD-B2-1021-F RF015B21AA RF075M43BA N
6 1500 W ASD-B2-1521-F RF015B21AA RF075M43BA N
7 2000 W ASD-B2-2023-F - RF037B43BA N
8 3000 W ASD-B2-3023-F - RF037B43BA N
EMI Filter Installation
All electronic equipment (including servo drive) generates high or low frequency noise during
operation and interfere the peripheral equipment via conduction or radiation. With EMI Filter and
the correct installation, much interference can be eliminated. It is suggested to use Delta’s EMI
Filter to suppress the interference better.
When installing servo drive and EMI Filter, please follow the instructions of the user manual and
make sure it meets the following specifications.
1. EN61000-6-4 (2001)
2. EN61800-3 (2004) PDS of category C2
3. EN55011+A2 (2007) Class A Group 1
