Delta ASDA-B2-F Series User Manual

ASDA-B2-F Absolute System
September, 2015 10-3
10
10.1 Absolute Type of Battery Box and Wiring Rods
10.1.1 Specifications
Precautions
Please carefully read through the following safety precautions. Use batteries in accordance with
the specification so as to avoid damages or dangers.
 The installation location shall have no water drop, corrosive gas and inflammable
gas.
 Correctly place the battery into battery box so as to avoid short circuiting.
 Do not short circuit the positive electrode and negative electrode of the battery;
or install the battery in reverse direction.
 It is suggested to use new batteries only. This is for avoiding losing electric
energy or shortening the lifetime of new batteries.
 Please follow the instructions when conduct wiring for battery box, or danger
may occur.
 Do not place the battery in a high-temperature environment (over 100℃) or it
might result in fire or explosion.
 It is non-rechargeable batteries. Do not charge the batteries or it might result in
explosion.
 Do not directly weld on the surface of the battery.
Battery Specifications
Items
Li/SOCl2 Cylindrical Battery
Type
ER14505
Delta Model Number
ASD-CLBT0100
International Standard Size
AA
Standard Voltage
3.6 V
Standard Capacity
2700 mAh
Maximum Continuous Discharge Current
100 mA
Maximum Pulse Current
200 mA
Dimensions (D x H)
14.5 x 50.5 mm
Weight
Approx. 19 g
Operating Temperature
-40～+85 ℃
