Delta ASDA-B2-F Series User Manual

ASDA-B2-F Parameters
September, 2015 7-49
7
P2-70 MRS Read Data Format Selection
A
ddress: 028CH
028DH
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
ALL
Unit: - Range: 0x00~0x07
Format: HEX Data Size: 16-bit
Settings:
Bit 0: Data unit setting of digital input / output (DI / DO); 1: pulse, 0: PUU.
Bit 1: Communication data unit setting; 1: pulse, 0: PUU.
Bit 2: Overflow warning; 1: No overflow warning; 0: Overflow warning, AL289 (PUU) and AL062
(pulse).
Bit 3 ~ Bit 15: Reserved. Must be set to 0.
P2-71■ CAP Absolute Position Homing
A
ddress: 028EH
028FH
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
ALL
Unit: - Range: 0 ~ 1
Format: HEX Data Size: 16-bit
Settings:
When P2-71 is set to 1, the current position will be set as home position. This function can be
enabled only when parameter P2-08 is set to 271.
P2-72~P2-79 Reserved
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
