Delta ASDA-B2-F Series

ASDA-B2-F Parameters
September, 2015 7-51
7
6: 8, N, 2(MODBUS, RTU) 7: 8, E, 1(MODBUS, RTU) 8: 8, O, 1(MODBUS, RUT)
P3-03 FLT Communication Error Disposal
A
ddress: 0306H
0307H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
ALL
Unit: - Range: 0 ~ 1
Format: HEX Data Size: 16-bit
Settings:
The definition of the setting value is as the followings:
0: Warning displays and motor keeps running
1: Warning displays and motor decelerates to stop (The deceleration time can be set via P5-03.B)
P3-04 CWD Communication Timeout
A
ddress: 0308H
0309H
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
ALL
Unit: sec Range: 0 ~ 20
Format: DEC Data Size: 16-bit
Settings:
If the setting value is not 0, the communication timeout function is enabled immediately. If it is set to
0, this function will be disabled.
P3-05 CMM Communication Mechanism
A
ddress: 030AH
030BH
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
ALL
Unit: - Range: 0x00 ~ 0x01
Format: HEX Data Size: 16-bit
Settings:
Communication interface selection (one or more than one communication)
Communication Interface: 0: RS-232
P3-06■ SDI Control Switch of Digital Input (DI)
A
ddress: 030CH
030DH
Operational
Interface:
Panel / Software Communication
Related
Section:
-
Default: 0
Control
Mode:
ALL
Unit: - Range: 0x0000 ~ 0x3FFF
Format: HEX Data Size: 16-bit
Settings:
Control switch of DI source. Each bit of this parameter decides one input source of DI signal:
Bit0 ~ Bit4 correspond to DI1 ~ DI5.
The setting of bit is as the followings:
0: The input status is controlled by the external hardware terminal.
1: The input status is controlled by P4-07.
For functional planning of digital input, please refer to:
DI1 ~ DI5: P2-10 ~ P2-14
