Delta ASDA-B2-F Series

ASDA-B2-F Parameters
September, 2015 7-25
7
Settings:
Internal Speed Command 2: The setting of the 2
nd
internal speed command
Internal Speed Limit 2: The setting of the 2
nd
internal speed limit
Example of inputting internal speed limit:
Speed Limit Setting
Value of P1-10
Allowable Speed
Range
Forward Speed
Limit
Reverse Speed
Limit
1000
-100 ~ 100 r/min 100 r/min -100 r/min
-1000
P1-11 SP3
Internal Speed Command 3
/
Internal Speed Limit
3
A
ddress: 0116H
0117H
Operational
Interface:
Panel / Software Communication
Related
Section:
6.3.1
Default: 3000
Control
Mode:
Sz (Internal Speed Command) / Tz
(Internal Speed Limit)
Unit: 0.1 r/min Range:
-60000 ~ +60000
Format: DEC Data Size: 32-bit
Example:
Internal Speed Command: 120 = 12 r/min
Internal Speed Limit: Positive value and negative value are the same. Please refer to the
following description.
Settings:
Internal Speed Command 3: The setting of the 3
rd
internal speed command
Internal Speed Limit 3: The setting of the 3
rd
internal speed limit
Example of inputting internal speed limit:
Speed Limit Setting
Value of P1-11
Allowable Speed
Range
Forward Speed
Limit
Reverse Speed
Limit
1000
100 ~ 100 r/min 100 r/min -100 r/min
-1000
P1-12 TQ1
Internal Torque Command 1
/
Internal Torque
Limit 1
A
ddress: 0118H
0119H
Operational
Interface:
Panel / Software Communication
Related
Section:
6.4.1
Default: 100
Control
Mode:
Tz (Internal Torque Command) /
DMCNET, Sz (Internal Torque
Limit)
Unit: % Range: -300 ~ +300
Format: DEC Data Size: 16-bit
Example:
Internal Torque Command: 30 = 30 %
Internal Torque Limit: Positive value and negative value are the same. Please refer to the
following description.
Settings:
Internal Torque Command 1: The setting of the 1
st
internal torque command
Internal Torque Limit 1: The setting of the 1
st
internal torque limit
Example of inputting internal torque limit:
Torque Limit Setting
Value of P1-12
Allowable Torque
Range
Forward Torque
Limit
Reverse Torque
Limit
30
-30 ~ 30 % 30 % -30 %
-30
P1-13 TQ2
Internal Torque Command 2
/
Internal Torque
Limit 2
A
ddress: 011AH
011BH
Operational
Interface:
Panel / Software Communication
Related
Section:
6.4.1
Default: 100
Control
Mode:
Tz (Internal Torque Command) / Sz
(Internal Torque Limit)
Unit: % Range: -300 ~ +300
Format: DEC Data Size: 16-bit
Example:
Internal Torque Command: 30 = 30 %
Internal Torque Limit: Positive value and negative value are the same. Please refer to the
following description.
Settings:
Internal Torque Command 2: The setting of the 2
nd
internal torque command
Internal Torque Limit 2: The setting of the 2
nd
internal torque limit
