Delta ASDA-B2-F Series User Manual

ASDA-B2-F Parameters
September, 2015 7-27
7
P1-27 VSF2 Low-frequency Vibration Suppression (2)
A
ddress: 0136H
0137H
Operational
Interface:
Panel / Software Communication
Related
Section:
6.2.6
Default: 1000
Control
Mode:
DMCNET
Unit: 0.1 Hz Range: 10 ~ 1000
Format: DEC Data Size: 16-bit
Example: 150 = 15 Hz
Settings:
The setting value of the second low-frequency vibration suppression. If P1-28 is set to 0, then it will
disable the second low-frequency filter.
P1-28 VSG2 Low-frequency Vibration Suppression Gain (2)
A
ddress: 0138H
0139H
Operational
Interface:
Panel / Software Communication
Related
Section:
6.2.6
Default: 0
Control
Mode:
DMCNET
Unit: - Range:
0 ~ 9 (0: Disable the second
low-frequency filter)
Format: DEC Data Size: 16-bit
Settings:
The second low-frequency vibration suppression gain. Higher setting value means better position
response. If the value is set to be too big, the motor will not be able to smoothly operate. It is
suggested to set the value to 1.
P1-29 AVSM
Auto Low-frequency Vibration Suppression
Setting
A
ddress: 013AH
013BH
Operational
Interface:
Panel / Software Communication
Related
Section:
6.2.6
Default: 0
Control
Mode:
DMCNET
Unit: - Range: 0 ~ 1
Format: DEC Data Size: 16-bit
Settings:
0: The auto-detection function is disabled.
1: Set back to 0 after vibration suppression.
Description of auto modes setting:
When the parameter is set to 1, it is in auto suppression. When the vibration frequency is not being
detected or the value of searched frequency is stable, the parameter will be set to 0 and the
frequency of low-frequency vibration suppression is saved to P1-25 automatically.
P1-30 VCL Low-frequency Vibration Detection
A
ddress: 013CH
013DH
Operational
Interface:
Panel / Software Communication
Related
Section:
6.2.6
Default: 500
Control
Mode:
DMCNET
Unit: Pulse Range: 1 ~ 8000
Format: DEC Data Size: 16-bit
Settings:
When auto suppression is enabled (P1-29 = 1), this parameter is used as the detection level. The
lower the value is, the more sensitive the detection will be. However, it is easier to misjudge noise
or regard other low-frequency vibration as the suppression frequency. If the value is bigger, it will
make more precise judgment. However, if the vibration of the mechanism is smaller, it might not
detect the frequency of low-frequency vibration.
P1-31 Reserved
