Delta ASDA-B2-F Series User Manual

ASDA-B2-F Communications
September, 2015 8-9
8
ASCII Mode:
Command Message (Master): Response Message (Slave):
Start
‘:’
Start
‘:’
Slave Address
‘0’
Slave Address
‘0’
‘1’ ‘1’
Function
‘1’
Function
‘1’
‘0’ ‘0’
Start Data Address
‘0’
Start Data Address
‘0’
‘1’ ‘1'
‘1’ ‘1’
‘2’ ‘2’
Data Number
(in word)
‘0’
Data Number
‘0’
‘0’ ‘0’
‘0’ ‘0’
‘2’ ‘2’
Data Number
(in byte)
‘0’
LRC Check
‘D’
‘4’ ‘A’
Content of the 1
st
Data
‘0’ End 1 (0DH)(CR)
‘B’ End 0 (0AH)(LF)
‘B’
‘8’
Content of the 2
nd
Data
‘0’
‘0’
‘0’
‘0’
LRC Check
‘1’
‘3’
End 1 (0DH)(CR)
End 0 (0AH)(LF)
