Delta ASDA-B2-F Series User Manual

ASDA-B2-F Absolute System
September, 2015 10-15
10
Dual Battery Box
Lift the top cover will pull
out the batteries.
Disconnect the connector and remove
the old batteries. Then, replace with the
new ones and connect the connector
again. Please complete it within 10
minutes so as to avoid data lose.
Cover the top
cover back.
Place the cables
toward the inner
side of the box
so that batteries
can be both
placed inside the
box.
Slightly press the hooks
on both sides to open
the top cover.
Please replace the
battery when the
power is still supplied
to the drive. Do not
remove the power
cable so as to avoid
data lose.
