Appendix A Specifications ASDA-B2-F
A-8 September, 2015
ECMA Series
E△13 E△18 F△13 F△18
05 10 15 20 20 30 08 13 30
Brake Power Consumption
(at 20˚C) [W]
19.0 19.0 19.0 19.0 20.4 20.4 19.0 19.0 20.4
Brake Release Time
[ms (Max)]
10 10 10 10 10 10
10 10
10
Brake Pull-in Time
[ms (Max)]
70 70 70 70 70 70 70 70 70
Vibration Grade (μm) 15
Operating Temperature (˚C) 0 ~ 40
Storage Temperature (˚C) -10 ~ 80
Operating Humidity 20 ~ 90%RH (non-condensing)
Storage Humidity
20 ~ 90%RH (non-condensing)
Vibration Capacity
2.5G
IP Rating
IP65 (when waterproof connectors are used, or when an oil seal is used to be
fitted to the rotating shaft (an oil seal model is used))
Approvals
Note:
*1 The rated torque is the continuous permissible torque between 0~40˚C operating temperature when
attaching with the following heat sink dimension:
ECMA-_ _ 04 / 06 / 08: 250 mm x 250 mm x 6 mm
ECMA-_ _ 10: 300 mm x 300 mm x 12 mm
ECMA-_ _ 13: 400 mm x 400 mm x 20 mm
ECMA-_ _ 18: 550 mm x 550 mm x 30 mm
Material: Aluminum – F40, F60, F80, F100, F130, F180
*2 The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to decelerate
or as the dynamic brake.
*3 For servo motor with magnetic encoder, please refer to the standard specifications of servo motors.
*4 The box (△) in the column stands for encoder type, please refer to Chapter 1 for detailed description.
To Next Page
