Delta ASDA-B2-F Series User Manual

Appendix A Specifications ASDA-B2-F
A-12 September, 2015
A
ECMA Series
C△06 C△08
04□H 07□H
Operating Humidity 20 ~ 90%RH (non-condensing)
Storage Humidity 20 ~ 90%RH (non-condensing)
Vibration Capacity 2.5 G
IP Rating
IP65 (when waterproof connectors are used, or when an oil seal
is used to be fitted to the rotating shaft (an oil seal model is
used))
Approvals
Note:
*1 The rated torque is the continuous permissible torque between 0~40˚C operating temperature when
attaching with the following heat sink dimension:
ECMA-_ _ 04 / 06 / 08: 250 mm x 250 mm x 6 mm
ECMA-_ _ 10: 300 mm x 300 mm x 12 mm
ECMA-_ _ 13: 400 mm x 400 mm x 20 mm
ECMA-_ _ 18: 550 mm x 550 mm x 30 mm
Material type: Aluminum – F40, F60, F80, F100, F130, F180
*2 The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to decelerate
or as the dynamic brake.
*3 For servo motor with magnetic encoder, please refer to the standard specifications of servo motors.
*4 The box (△) in the column stands for encoder type, please refer to Chapter 1 for detailed description.
