Wiring ASDA-B2-F
3-6 September, 2015
3
Wiring Name
U
(Red)
V
(White)
W
(Black)
CASE
GROUND
(Green)
BRAKE1
(Yellow)
BRAKE2
(Blue)
Terminal
Definition A
1 2 3 4 - -
Terminal
Definition B
1 2 4 5 3 6
Terminal
Definition C
F I B E G H
Terminal
Definition D
D E F G A B
When selecting the wire rod, please choose 600 V PVC cable and the length should be no longer
than 30 m. If the length exceeds 30 m, please take the received voltage into consideration when
selecting the wire size. Please refer to Section 3.1.6 for wire rod selection.
Note:
1. No polarity for brake coil, the wiring name is BRAKE1 & BRAKE2.
2. Power for brake is 24 V
DC
. Never share it with the power of control signal V
DD
.
3. Box, () in servo motor model represents brake or keyway / oil seal.
4. Triangle, (
)
in servo motor model represents encoder type. Please see Chapter 1 for detail.
