ASDA-M Chapter 8 Parameters
Revision December, 2014 8-111
Settings：
If users do not know how to set P2-54~P2-56, setting the
bandwidth of synchronous control value will do since the value
will correspond to P2-54~P2-56. The bigger the bandwidth of
synchronous control value is, the better the synchronous effect
will be. When increasing the bandwidth of speed loop and
synchronous control, pay special attention to the response of
P2-25 which should be faster than the setting of the both
bandwidth.
(Firmware, V1.005 sub00 will be provided soon)
P2-58 GTRY Gantry Function
Address: 0274H
0275H
Parameter
Attribute：
Parameter for individual axis
Related Section: -
Operational
Interface：
Panel / Software Communication
Default：
X Axis: 0000h
Y Axis: 0010h
Z Axis: 0020h
Control
Mode：
ALL
Unit：
-
Range：
0000h ~ 0x1021
Data Size：
16bit
Format：
HEX
