Delta DVP-PM Series User Manual

9 Electrical CAM
DVP-PM Application Manual
9-40
50
0
0
-500
0
100
200 300 400 500
600
700
800
900
1,000
500
Displacement
Degree
Length of Slave:
Degree
1
0
-1
0
100
200 300
400
500
600
700
800
900
1,000
Length of sync area of Slave:
30
0
Length of Master:
1,000
Magnification of Slave:
F1.0
Velocity
Parameters SV
Length of Master 1000
Length of Slave 500
Length of sync area 200
Magnification ratio 1.0
Max magnification
ratio
10.0
Acceleration curve 0
CAM curve 0
CAM curve setting
Only single
data
real-time
modification
is applicable
Results 0
Control Steps:
Step 1: Add 2 sets of E-CAM charts and set the resolution as 300.
Step 2: Download the below program in DVP-20PM and execute.
Step 3: Set M1 to write the parameters for rotary cut E-CAM into D100~D112 and CR#10000 into D0
Step 4: Set M0 to write the data in D100~D112 into special register CR#10000 to generate the rotary cut
E-CAM curve.
Step 5: Stop the DVP-PM and upload the program.
Step 6: Monitor the uploaded E-CAM Chart-0, which is the generated rotary cut E-CAM curves.
Ladder Diagram:
