Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-22
Special
M
Function 10M
20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
M1831*
Enable current position write in function on Y-axis ○○○OFF
- - R/W NO OFF
3-44
M1841*
Stop Y axis movement at fixed position ╳ ○○OFF
- - R/W NO OFF
3-44
M1872* Y axis ready flag
○○○
ON ON ON R
NO
ON 3-44
M1873*
Error flag of motion subroutine on Y axis; (automatically
cleared when Y axis is re-activated)
○○○
OFF - - R
NO
OFF 3-45
M1908 Input signal control of C200/C204 ╳ ○○OFF - - R/W NO OFF -
M1909 Virtual Master setting 1
╳
○○OFF - - R/W NO OFF
M1910 Virtual Master setting 2
╳
○○OFF - - R/W NO OFF
M1920 Radian / degree selection in O100
○○○
OFF - - R/W
NO
OFF -
M1952 O100 ready flag
○○○
ON OFF ON R
NO
ON -
M1953* Error flag of O100
○○○
OFF OFF - R/W
NO
OFF 3-50
M1957 Indicate AUTO / MANU (STOP / RUN) status
○○○
OFF ON - R
NO
OFF -
M1968 Zero flag for O100
○○○
OFF - - R
NO
OFF -
M1969 Borrow flag for O100
○○○
OFF - - R
NO
OFF -
M1970 Carry flag for O100
○○○
OFF - - R
NO
OFF -
M1971 Error flag for O100 floating point operation
○ ○ ○
OFF - - R
NO
OFF -
M1985 Disable zero return of Z axis
╳
╳
○
OFF - - R/W
NO
OFF -
M1991* Enable current position write-in function on Z-axis ○○○OFF - - R/W NO OFF
3-44
M2001*
Stop Z axis movement at fixed position ○○○OFF
- - R/W NO OFF
3-44
M2032* Z axis ready flag
╳ ╳ ○
OFF ON ON R
NO
ON 3-44
M2033*
Error flag of motion subroutine on Z axis; (automatically
cleared when Y axis is re-activated)
╳ ╳ ○
OFF - - R/W
NO
OFF 3-45
M2065 Disable zero return of A axis
○
╳ ╳
OFF - - R/W
NO
OFF -
M2071* Enable current position write-in function on A-axis
○
╳ ╳
OFF - - R/W
NO
OFF 3-44
M2112* A axis ready flag
○
╳ ╳
ON ON ON R
NO
ON 3-44
M2113*
Error flag of motion subroutine on Z axis; (automatically
cleared when Y axis is re-activated)
○ ╳ ╳
OFF - - R/W
NO
OFF 3-45
Note: 10M = DVP10PM, 20D = DVP20PM00D, 20M = DVP20PM00M
