3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-24
Special
D
Function
10M 20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
receiving data
D1124
COM2(RS-485) Definition of start character (STX)
â—‹ â—‹ â—‹
H’3A - - R/W NO H’3A
D1125
COM2(RS-485) Definition of first ending character
(ETX1)
â—‹ â—‹
â—‹
H’0D - - R/W NO H’0D
D1126
COM2(RS-485) Definition of second ending character
(ETX2)
â—‹ â—‹ â—‹
H’0A - - R/W NO H’0A
D1129 COM2 (RS-485) Communication time-out setting (ms)
â—‹ â—‹ â—‹
0 - - R/W
NO
0 -
D1130 COM2 (RS-485) Error code returning from Modbus
â—‹ â—‹ â—‹
0 0 - R
NO
0 -
D1140* Number of right-side modules (max. 8)
â—‹ â—‹ â—‹
0 - - R
NO
0 3-42
D1142* Number of input points (X) on DIO modules
â—‹ â—‹ â—‹
0 - - R
NO
0 3-42
D1143* Number of output points (Y) on DIO modules
â—‹ â—‹ â—‹
0 - - R
NO
0 3-42
D1149
ID of function card (0: no card inserted; 3: COM3 card;
8: 2AD card; 9: 2DA card)
â—‹ â—‹ â—‹
0 - - R
NO
0 -
D1200* Start address of latched memory for auxiliary relays M
â—‹ â—‹ â—‹
- - - R/W
YES
500 3-42
D1201* End address of latched memory for auxiliary relays M
â—‹ â—‹ â—‹
- - - R/W
YES
999 3-42
D1202* Start address of latched memory for timer T
â—‹ â—‹ â—‹
- - - R/W
YES
-1 3-42
D1203* End address of latched memory for timer T
â—‹ â—‹ â—‹
- - - R/W
YES
-1 3-42
D1204* Start address of latched memory for 16-bit counter C
â—‹ â—‹ â—‹
- - - R/W
YES
100 3-42
D1205* End address of latched memory for 16-bit counter C
â—‹ â—‹ â—‹
- - - R/W
YES
199 3-42
D1206* Start address of latched memory for 32-bit counter C
â—‹ â—‹ â—‹
- - - R/W
YES
220 3-42
D1207* End address of latched memory for 32-bit counter C
â—‹ â—‹ â—‹
- - - R/W
YES
255 3-42
D1208* Start address of latched memory for step relay S
â—‹ â—‹ â—‹
- - - R/W
YES
500 3-42
D1209* End address of latched memory for step relay S
â—‹ â—‹ â—‹
- - - R/W
YES
1,023 3-42
D1210* Start address of latched memory for data register D
â—‹ â—‹ â—‹
- - - R/W
YES
200 3-42
D1211* End address of latched memory for data register D
â—‹ â—‹ â—‹
- - - R/W YES 9,999 3-42
D1320* ID of the 1
st
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1321* ID of the 2
nd
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1322* ID of the 3
rd
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1323* ID of the 4
th
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1324* ID of the 5
th
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1325* ID of the 6
th
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1326* ID of the 7
th
right-side module
â—‹ â—‹ â—‹
0 - - R
NO
0 3-43
D1327* ID of the 8
th
right-side module
â—‹
â—‹ â—‹
0 - - R
NO
0 3-43
D1328*
Target position (low word) of the third axis control by
G-code (G00, G01)
D1329*
Target position (high word) of the third axis control by
G-code (G00, G01)
╳ ╳ ○
0 - - R/W
NO
NO
6-46
D1330*
Max positioning speed (D1330 = K-1) of the third axis
by G-code, G00 (low word)
╳ ╳ ○
0 - - R/W
NO
NO
6-46
