3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-25
Special
D
Function
10M 20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
Insterpolation speed of the third axis by G-code, G01.
(low word)
6-48
Max positioning speed (D1330 = K-1) of the third axis
by G-code, G00 (high word)
6-46
D1331*
Insterpolation speed of the third axis by G-code, G01.
(high word)
╳ ╳
○
0 - - R/W
NO NO
6-48
D1400* Enable interruption
○ ○ ○
0 - - R/W
NO
0 3-43
D1401* Interrupt interval for timer interrupt (ms)
○ ○ ○
0 - - R/W
NO
0 3-43
D1500 FROM/TO data area, corresponding to CR#0
○ ○ ○
H’6260 - - R
NO
H’6260 -
D1501
↓
D1699
FROM/TO data area, corresponding to CR#1 ~
CR#199
○ ○ ○
0 - - R/W
NO
0 -
D1700 The executing No. of OX
○ ○ ○
0 - - R
NO
0 -
D1702 Step No. of the executing OX subroutine
○ ○ ○
0 - - R
NO
0 -
D1703* The executing M-code
○ ○ ○
0 - - R
NO
0 3-44
D1704 Pause time of OX subroutine
○ ○ ○
0 - - R
NO
0 -
D1705 Present pause time of OX
○ ○ ○
0 - - R
NO
0 -
D1706 Set value of RPT instruction in OX subroutine
○ ○ ○
0 - - R
NO
0 -
D1707 Present value of RPT instruction in OX subroutine
○ ○ ○
0 - - R
NO
0 -
D1708 Offset value for target position of X-axis (low word)
D1709 Offset value for target position of X-axis (high word)
○ ○ ○
0 - - R
NO
0 -
D1710 Offset for distance to center of arc on X-axis (low word)
D1711
Offset for distance to center of arc on X-axis (high
word)
╳ ○ ○
0 - - R
NO
0 -
D1712 Offset value of arc radius (low word)
D1713 Offset value of arc radius (high word)
╳ ○ ○
0 - - R
NO
0 -
D1724 Offset value for target position of Y-axis (low word)
D1725 Offset value for target position of Y-axis (high word)
╳
○ ○
0 - - R
NO
0 -
D1726 Offset for distance to center of arc on Y-axis (low word)
D1727
Offset for distance to center of arc on Y-axis (high
word)
╳
○ ○
0 - - R
NO
0
D1736 Pause time (TIM) of O100
○ ○ ○
0 - - R
NO
0 -
D1737 Present pause time (TIM) of O100
○ ○ ○
0 - - R
NO
0 -
D1738 Set value of RPT instruction in O100
○ ○ ○
0 - - R
NO
0 -
D1739 Present value of RPT instruction in O100
○ ○ ○
0 - - R
NO
0 -
D1796* Deceleration speed for continuous interpolation
○ ○ ○
0 - - R
NO
0 3-46
D1798* Percentage value of G-Code moving speed
○ ○ ○
0 - - R
NO
0 3-47
D1799* Input terminal polarity (for X/Y-axis)
○ ○ ○
0 - - R/W
NO
0 3-47
D1800* Status of input terminal
○ ○ ○
0 - - R
NO
0 3-48
