Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-26
Special
D
Function
10M 20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
D1802* Error code of O100
○ ○ ○
0 - - R/W
NO
0 3-50
D1803* Error STEP of O100
○ ○ ○
0 0 - R/W
NO
0 3-50
D1804* Input terminal polarity 2 (for Z-axis)
╳ ╳ ○
0 - - R/W
NO
0 3-48
D1805* Input terminal status 2 (for Z-axis)
╳ ╳ ○
0 - - R
NO
0 3-49
D1806*
High Byte: Filter coefficient of MPG0 / MPG1
Low Byte: Filter coefficient of other input points other
than X points. Filter frequency: 85000/2N+4(kHz)
○ ○ ○ 0
- - R/W
NO
0
3-49
D1816* Parameter setting of X axis
○ ○ ○
- - - R/W
YES
0 3-50
D1818 Pulses per revolution (PPR) on X axis (low word)
D1819 Pulses per revolution (PPR) on X axis (high word)
○ ○ ○
- - - R/W
YES
2,000 -
D1820
Displacement per revolution (DPR) of motor on X axis
(low word)
D1821
Displacement per revolution (DPR) of motor on X axis
(high word)
○ ○ ○
- - - R/W
YES
1,000 -
D1822 Maximum speed on X axis: V
MAX
(low word)
D1823 Maximum speed on X axis: V
MAX
(high word)
○ ○ ○
- - - R/W
YES
500K -
D1824 Bias speed of X axis: V
BIAS
(low word)
D1825 Bias speed of X axis: V
BIAS
(high word)
○ ○ ○
- - - R/W
YES
0 -
D1826 JOG speed of X axis: V
JOG
(low word)
D1827 JOG speed of X axis: V
JOG
(high word)
○ ○ ○
- - - R/W
YES
5,000 -
D1828 Zero return speed of X axis: V
RT
(low word)
D1829 Zero return speed of X axis: V
RT
(high word)
○ ○ ○
- - - R/W
YES
50K -
D1830
Zero return deceleration speed of X axis: V
CR
(low
word)
D1831
Zero return deceleration speed of X axis: V
CR
(high
word)
○ ○ ○
- - - R/W
YES
1,000 -
Number of Zero point signals (PG0) on X axis:N
○
○ ○
- - - R/W
YES
0 3-51
D1832*
Times of acyclic CAM repetitions
╳
○ ○
- - - R/W
YES
0 -
Number of pulses for zero return on X axis: P
○
○ ○
- - - R/W
YES
0 3-51
D1833*
Distribution of remaining acyclic CAM pulses
╳
○ ○
- - - R/W
YES
0 -
Definition of zero point on X axis: HP (low word)
○
○ ○
- - - R/W
YES
0 3-51
D1834
Pulses for delay start of acyclic CAM
╳
○ ○
- - - R/W
YES
0 -
Definition of zero point on X axis: HP (high word)
○
○ ○
- - - R/W
YES
0 -
D1835
Pulses for delay start of CAM
╳
○ ○
- - - R/W
YES
0 -
D1836 Acceleration time of X axis: T
ACC
○ ○ ○
- - - R/W
YES
500 -
D1837 Deceleration time of X axis: T
DEC
○ ○ ○
- - - R/W
YES
500 -
Target position (I) of X axis: P(I) (low word)
○ ○ ○ ○
- - R/W
NO
0 -
D1838
Lower bound of CAM synchronized output (low word)
╳
○ ○ ○-
- - R/W
NO
0 -
