Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-29
Special
D
Function
10M 20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
D1887 Accumulated error value on X axis (High word)
╳
○ ○
- - - R
NO
0 -
D1888*
The max accumulated error value on X axis
(Low word)
╳
○ ○
- - - R
NO
0 3-55
D1889
The max accumulated error value on X axis
(High word)
╳
○ ○
- - - R
NO
0 3-55
D1896* Parameter setting of Y axis
╳
○ ○
- - - R/W
YES
0 3-50
D1898 Pulses per revolution (PPR) on Y axis (low word)
D1899 Pulses per revolution (PPR) on Y axis (high word)
╳
○ ○
- - R/W
YES
2,000 -
D1900
Displacement per revolution (DPR) of motor on Y axis
(low word)
D1901
Displacement per revolution (DPR) of motor on Y axis
(high word)
○ ○ ○
- - - R/W
YES
1,000 -
D1902 Maximum speed on Y axis: V
MAX
(low word)
D1903 Maximum speed on Y axis: V
MAX
(high word)
○ ○ ○
- - - R/W
YES
500K -
D1904 Bias speed of Y axis: V
BIAS
(low word)
D1905 Bias speed of Y axis: V
BIAS
(high word)
○ ○ ○
- - - R/W
YES
0 -
D1906 JOG speed of Y axis: V
JOG
(low word)
D1907 JOG speed of Y axis: V
JOG
(high word)
○ ○ ○
- - - R/W
YES
5,000 -
D1908 Zero return speed of Y axis: V
RT
(low word)
D1909 Zero return speed of Y axis: V
RT
(high word)
○ ○ ○
- - - R/W
YES
50K -
D1910
Zero return deceleration speed of Y axis: V
CR
(low
word)
D1911
Zero return deceleration speed of Y axis: V
CR
(high
word)
○ ○ ○
- - - R/W
YES
1,000 -
D1912 Number of Zero point signals (PG0) on Y axis:N
○ ○ ○
- - - R/W
YES
0 -
D1913 Number of pulses for zero return on Y axis: P
○ ○ ○
- - - R/W
YES
0 -
D1914 Definition of zero point on Y axis: HP (low word)
D1915 Definition of zero point on Y axis: HP (high word)
○ ○ ○
- - - R/W
YES
0 -
D1916 Acceleration time of Y axis: T
ACC ○ ○ ○
- - - R/W
YES
500 -
D1917 Deceleration time of Y axis: T
DEC ○ ○ ○
- - - R/W
YES
500 -
Target position (I) of Y axis: P(I) (low word)
○ ○ ○
0 - - R/W
NO
0 -
D1918
PWM pulse width setting on Y axis (low word)
○
╳ ╳
0 - - R/W
NO
0 -
Target position (I) of Y axis: P(I) (high word)
○ ○ ○
0 - - R/W
NO
0 -
D1919
PWM pulse width setting on Y axis (high word)
○
╳ ╳
0 - - R/W
NO
0 -
D1920 Operation speed (I) of Y axis: V(I) (low word)
D1921 Operation speed (I) of Y axis: V(I) (high word
○ ○ ○
1,000 - - R/W
NO
1,000 -
Target position (II) of Y axis: P(II) (low word)
○ ○ ○
0 - - R/W
NO
0 -
D1922
PWM cycle setting on Y axis (low word)
○
╳ ╳
0 - - R/W
NO
0 -
D1923
Target position (II) of Y axis: P(II) (high word)
○ ○ ○
0 - - R/W
NO
0 -
