Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-33
Special
D
Function
10M 20D 20M
OFF
Ø
ON
MANU
Ø
AUTO
AUTO
Ø
MANU
Attrib. Latched Default
Page
number
D2048
The max accumulated error value on Z axis
(Low word)
╳ ╳
○
- - - R
NO
0 -
D2049
The max accumulated error value on Z axis
(High word)
╳ ╳
○
- - - R
NO
0 -
D2056*
Parameter setting of A axis
○
╳ ╳
- -
- R/W
YES
0
3-50
D2058
Pulses per revolution (PPR) on A axis (low word)
D2059
Pulses per revolution (PPR) on A axis (high word)
○
╳ ╳
- - - R/W
YES
2000 -
D2060
Displacement per revolution (DPR) of motor on A axis
(low word)
D2061
Displacement per revolution (DPR) of motor on A axis
(high word)
○
╳ ╳
- - -
YES
1000
D2062
Maximum speed on A axis: V
MAX
(low word)
D2063
Maximum speed on A axis: V
MAX
(high word)
○
╳ ╳
- - - R/W
YES
500K -
D2064
Bias speed of A axis: V
BIAS
(low word)
D2065
Bias speed of A axis: V
BIAS
(high word)
○
╳ ╳
- - - R/W
YES
0 -
D2066
JOG speed of A axis: V
JOG
(low word)
D2067
JOG speed of A axis: V
JOG
(high word)
○
╳ ╳
- - - R/W
YES
5000 -
D2068
Zero return speed of A axis: V
RT
(low word)
D2069
Zero return speed of A axis: V
RT
(high word)
○
╳ ╳
- - - R/W
YES
50K -
D2070
Zero return deceleration speed of A axis: V
CR
(low
word)
D2071
Zero return deceleration speed of A axis: V
CR
(high
word)
○
╳ ╳
- - - R/W
YES
1000 -
D2072 Number of Zero point signals (PG0) on A axis:N
○
╳ ╳
- -
- R/W
YES
0
-
D2073 Number of pulses for zero return on A axis: P
○
╳
- -
- R/W
YES
0
-
D2074 Definition of zero point on A axis: HP (low word)
D2075 Definition of zero point on A axis: HP (high word)
○
╳ ╳
- - - R/W
YES
0 -
D2076
Acceleration time of A axis: T
ACC
○
╳ ╳
- -
- R/W
YES
500
-
D2077
Deceleration time of A axis: T
DEC
○
╳ ╳
- -
- R/W
YES 500
-
Target position (I) of A axis: P(I) (low word)
○
╳ ╳
0 - - R/W NO 0 -
D2078
PWM pulse width setting on A axis (low word)
○
Target position (I) of A axis: P(I) (high word)
○
╳ ╳
D2079
PWM pulse width setting on X axis (lhigh word)
○
D2080 Operation speed (I) of A axis: V(I) (low word)
D2081 Operation speed (I) of A axis: V(I) (high word)
○
╳ ╳
1000 - - R/W NO 1000 -
Target position (II) of A axis: P(II) (low word)
D2082
PWM cycle setting on A axis (low word)
○
╳ ╳
0 - - R/W NO 0 -
Target position (II) of A axis: P(II) (high word)
D2083
PWM cycle setting on A axis (high word)
○
╳ ╳
