Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-48
bit# Input terminal polarity
1 PG0
2 DOG1
3 PG1
4 DOG2
5 PG2
6 DOG3
7 PG3
Function Group:
Reading the Status of Input Terminal
Number:
D1800
Explanations:
When there is signal input at the input terminal, the corresponding bit# = ON. If not, the corresponding bit# = OFF.
20PM:
bit# Input terminal status on X axis bit# Input terminal status on Y axis
0
PG0
8 PG0
1
MPGB0
9 MPGB1
2
MPGA0
10 MPGA1
3
LSN
11 LSN
4
LSP
12 LSP
5
DOG
13 DOG
6
STOP
14 STOP
7
START
15 START
10PM:
bit# Input terminal status
0 DOG0
1 PG0
2 DOG1
3 PG1
4 DOG2
5 PG2
6 DOG3
7 PG3
Function Group:
Setting up
Input terminal polarity 2 (for Z-axis)
Number:
D1804
Explanations:
