Delta ME300 Series User Manual

Chapter 9 Specification
ME300
9-2
9-1 115V Models
115V, one-phase
Frame A C
Model VFD_ _ _ ME11_ _ _AA
0A8
1A6
2A5
4A8
ANN ANS ANN ANS ANN ANS ANN ANS
Applicable Motor Output (kW) 0.1 0.2 0.4 0.75
Applicable Motor Output (HP) 1/8 1/4 1/2 1
Output Rating
Heavy
duty
Rated Output Capacity (kVA) 0.4 0.6 1.0 1.8
Rated Output Current (A)
0.8
1.6
2.5
4.8
Carrier Frequency (kHz) 2–15
Normal
Duty
Rated Output Capacity (kVA) 0.4 0.7 1.0 2.1
Rated Output Current (A) 1.0 1.8 2.7 5.5
Carrier Frequency (kHz) 2–15
Input Rating
Rated Input
Current (A)
Heavy Duty 3.0 6.0 9.4 18
Normal Duty 3.7 6.8 10.1 20.6
Rated Voltage / Frequency One-phase AC 100–120 V (-15– +10%), 50/60 Hz
Operating Voltage Range (V
AC
) 85–132
Frequency Range (Hz) 47–63
Weight (kg) 0.4 0.4 0.5 1
Cooling Method Convective cooling Fan cooling
EMC Filter
Optional
Ingress Protection Rating IP20
Table 9-1
NOTE:
1. Default: heavy duty.
2. The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current. See the derating
curve diagram in Section 9-6 for more information.
3. When the load is a shock or impact load, use a higher level model.

Delta ME300 Series Specifications

General

Power Rating	0.4 kW ~ 110 kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication	RS-485
Storage Temperature	-20-60°C
Dimensions	Varies by model
Weight	Varies by model
Input Voltage	3-phase 220VAC
Humidity	90% RH, non-condensing
