9-5 Environment for Operation, Storage and Transportation
DO
NOT expose the AC motor drive to bad environmental conditions, such as dust, direct sunlight, corrosive/
inflammable gasses, humidity, liquid or vibration. The salt in the air must be less than 0.01 mg/ cm
2
every year.
Environment
Installation
location
IEC60364-1/
IEC60664-1 Pollution degree 2, Indoor use only.
Surrounding
Temperature
Operation
IP20 / UL Open Type
-20–50
°C
-20–60
°C (Derating required)
IP20 installed side by side
-20–40
°C
-20–55
°C (Derating required)
NEMA 1 / UL Type 1
Storage
-40–85
°C
Transportation
-20–70
°C
Non-condensing, non-freezing
Rated Humidity
Operation Max. 90%
Storage / Transportation Max. 95%
No condense water
Air Pressure
Operation 86–106 kPa
Storage / Transportation 70–106 kPa
Pollution Level
Operation
Class 3C2; Class 3S2
Storage Class 2C2; Class 2S2
Transportation Class 1C2; Class 1S2
Concentrate prohibited
Altitude Operable at altitude below 1000 m (derating if operated over 1000 m)
Package
Drop
Storage
ISTA procedure 1A (according to weight) IEC 60068-2-31
Transportation
Vibration
Operating
1.0 mm, peak to peak value range from 2–13.2 H
z; 0.7–1.0 G range from
13.2–55 Hz; 1.0 G range from 55–512
Hz; complies with IEC 60068-2-6.
Non-operating
2.5 G peak
5 Hz–2 kHz
0.015" maximum di
splacement
Impact
Operating 15 G, 11 ms; comp
lies with IEC / EN 60068-2-27.
Non-operating
30 G
Table 9-6
