Chapter 9 Specification
ME300
9-4 General Specifications
Control
Characteristics
V/F, SVC
Applied Motor IM (Induction Motor), PM motor control (IPM and SPM)
Max. Output
Frequency
0.00–599.00 Hz
[Note]
150% / 3 Hz
100% / (1/20 of motor rated frequency)
(V/F, SVC for IM, Heavy duty)
(SVC control for PM, Heavy duty)
Speed Control
Range [Note]
1: 5 (V/F, SVC for IM, Heavy duty)
1: 20 (SVC control for PM, Heavy duty)
Overload
Capability
Normal duty:
120% of rated current can endure for 1 minute during every 5 minutes
150% of rated current can endure for 3 seconds during every 36 seconds.
Heavy duty:
150% of rated current can endure for 1 minute during every 5 minutes
200% of rated current can endure for 3 seconds during every 36 seconds
Frequency
Setting Signal
0–10 V / 4(0)–20 mA
PWM pulse width input, pulse input (10 kHz).
Main Function
Multiple motor switches (Two independent motor parameter settings), Fast
start-up, Deceleration Energy Back (DEB) function, Fast deceleration function,
Master and Auxiliary frequency source selectable, Momentary power loss ride
thru, Speed search, Over-torque detection, Torque limit, 16-step speed (max.),
Accel. / decel. time switch, S-curve accel. / decel., three-wire sequence, JOG
frequency, Upper / lower limits for frequency reference, DC injection braking at
start and stop, PID control, Positioning function.
Application
Macro
Built-in application parameter groups (selected by industry) and user-defined
application parameter groups.
Protection
Characteristics
Motor
Protection
Over-current, Over-voltage, Over-temperature, Phase loss, Over-load
Stall prevention during acceleration, deceleration and running (independent
settings)
Accessory
STO (Safe Torque Off) card
Certifications UL, CE, RCM, TÜV (SIL 2), RoHS, REACH, KC
Table 9-5
NOTE:
Control accuracy may vary depending on the environment, application conditions or different motors. For details, contact our
company or your local distributor.
