Delta ME300 Series - 9-3 460 V Models

Chapter 9 Specification
ME300
9-5
9-3 460V Models
460V, three-phase
Frame A B A B B C
Model VFD_ _ _ ME43 _ _ _AA
1A5
2A7
4A2
5A5
ANN ANS AFN AFS ANN ANS AFN AFS ANN ANS AFN AFS ANN ANS AFN AFS
Applicable Motor Output (kW) 0.4 0.75 1.5 2.2
Applicable Motor Output (HP) 1/2 1 2 3
Output Rating
Heavy
duty
Rated Output Capacity (kVA)
1.1 4.2 3.2 4.2
Rated Output Current (A)
1.5
2.7
4.2
5.5
Carrier Frequency (kHz) 2–15
Normal
Duty
Rated Output Capacity (kVA)
1.4 2.3 3.5 5.0
Rated Output Current (A) 1.8 3 4.6 6.5
Carrier Frequency (kHz) 2–15
Input Rating
Rated Input
Current (A)
Heavy Duty 1.7 3.0 4.6 6.1
Normal Duty 2.0 3.3 5.1 7.2
Rated Voltage / Frequency Three-phase AC 380V–480V (-15 %~+10 %), 50/60 Hz
Operating Voltage Range (V
AC
) 323–528
Frequency Range (Hz) 47–63
Weight (kg) 0.55 0.9 0.7 0.9 0.8 0.9 1 1.5
Cooling Method
Convective
cooling
Fan cooling
Convective
cooling
Fan cooling
EMC Filter
Optional
Built-in
Optional
Built-in
Optional
Built-in
Optional
Built-in
Ingress Protection Rating
IP20
Frame C
D
Model VFD_ _ _ ME43 _ _ _AA
7A3 9A0 13A 17A
ANN ANS AFN AFS ANN ANS AFN AFS ANN ANS AFN AFS ANN ANS AFN AFS
Applicable Motor Output (kW) 3 3.7 / 4 5.5 7.5
Applicable Motor Output (HP) 4 5 7.5 10
Output Rating
Heavy
duty
Rated Output Capacity (kVA)
5.6
6.9
9.9
13
Rated Output Current (A) 7.3 9 13 17
Carrier Frequency (kHz) 2–15
Normal
Duty
Rated Output Capacity (kVA)
6.1 8.0 12 15.6
Rated Output Current (A) 8 10.5 15.7 20.5
Carrier Frequency (kHz)
2–15
Input Rating
Rated Input
Current (A)
Heavy Duty 8.1 9.9 14.3 18.7
Normal Duty 8.9 11.6 17.3 22.6
Rated Voltage / Frequency Three-phase AC 380V–480V (-15 %~+10 %), 50/60 Hz
Operating Voltage Range (V
AC
) 323–528
Frequency Range (Hz) 47–63
Weight (kg) 1 1.5 1 1.5 2 2.7 2 2.7
Cooling Method
Fan cooling
EMC Filter Optional Built-in Optional Built-in Optional Built-in Optional Built-in
Ingress Protection Rating IP20
Table 9-4
NOTE:
1. Default: heavy duty.
2. The value of the carrier frequency is set in the factory. To increase the carrier frequency, decrease the current. See the derating
curve diagram in Section 9-6 for more information.
3. When the load is a shock or impact load, use a higher level model.
