Chapter 11 Summary of Parameter SettingsME300
11-2
This chapter provides a summary of parameter (Pr.) setting ranges and defaults. You can set,
change, and reset parameters through the digital keypad.
NOTE
: You can set this parameter during operation
The following are abbreviations for different types of motors:
 IM: Induction motor
 PM: Permanent magnet synchronous AC motor
 IPM: Interior permanent magnet synchronous AC motor
 SPM: Surface permanent magnet synchronous AC motor
00 Drive Parameters
Pr. Explanation Settings Default
00-00
AC motor drive identity
code
101: 115 V, 1 Phase, 0.125 HP
102: 115 V, 1 Phase, 0.25 HP
103: 115 V, 1 Phase, 0.5 HP
104: 115 V, 1 Phase, 1 HP
301: 230 V, 1 Phase, 0.125 HP
302: 230 V, 1 Phase, 0.25 HP
303: 230 V, 1 Phase, 0.5 HP
304: 230 V, 1 Phase, 1 HP
305: 230 V, 1 Phase, 2 HP
306: 230 V, 1 Phase, 3 HP
201: 230 V, 3 Phase, 0.125 HP
202: 230 V, 3 Phase, 0.25 HP
203: 230 V, 3 Phase, 0.5 HP
204: 230 V, 3 Phase, 1 HP
205: 230 V, 3 Phase, 2 HP
206: 230 V, 3 Phase, 3 HP
207: 230 V, 3 Phase, 5 HP
208: 230 V, 3 Phase, 7.5 HP
209: 230 V, 3 Phase, 10 HP
210: 230 V, 3 Phase, 15 HP
211: 230 V, 3 Phase, 20 HP
403: 460 V, 3 Phase, 0.5 HP
404: 460 V, 3 Phase, 1 HP
405: 460 V, 3 Phase, 2 HP
406: 460 V, 3 Phase, 3 HP
407: 460 V, 3 Phase, 5 HP
408: 460 V, 3 Phase, 7.5 HP
409: 460 V, 3 Phase, 10 HP
410: 460 V, 3 Phase, 15 HP
Read only
