Delta ME300 Series - Page 156

Chapter 11 Summary of Parameter SettingsME300
11-3
Pr. Explanation Settings Default
411: 460 V, 3 Phase, 20 HP
412: 460 V, 3 Phase, 25 HP
413: 460 V, 3 Phase, 30 HP
482: 460 V, 3 Phase, 4 HP
00-01
AC motor drive rated
current display
Display by model Read only
00-02 Parameter reset
0: No function
1: Write protection for parameters
5: Reset kWh displays to 0
8: Keypad does not respond
9: Reset all parameters to defaults
(base frequency is 50 Hz)
10: Reset all parameters to defaults
(base frequency is 60 Hz)
11: Reset all parameters to defaults with base frequency
at 50 Hz (keep the user-defined parameter values
Pr.13-01–Pr.13-50)
12: Reset all parameters to defaults with base frequency
at 60 Hz (keep the user-defined parameter values
Pr.13-01–Pr.13-50)
0

00-03 Select start-up display
0: F (frequency command)
1: H (output frequency)
2: U (user-defined, refer to Pr.00-04)
3: A (output current)
0

00-04
Content of multi-function
display (user-defined)
0: Display output current (A) (unit: Amp)
1: Display counter value (c) (unit: CNT)
2: Display the drive’s actual output frequency (H.)
(unit: Hz)
3: Display the drive’s DC bus voltage (V) (unit: V
DC
)
4: Display the drive’s output voltage (E) (unit: V
AC
)
5: Display the drive’s output power angle (n) (unit: deg)
6: Display the drive’s output power (P) (unit: kW)
7: Display the motor speed (rpm) (unit: rpm)
10: Display PID feedback (b) (unit: %)
11: Display AVI analog input terminal signal (1.) (unit: %)
12: Display ACI analog input terminal signal (2.) (unit: %)
14: Display the drive’s IGBT temperature (i.) (unit:
o
C)
16: The digital input status (ON / OFF) (i)
17: The digital output status (ON / OFF) (o)
18: Display multi-step speed (S)
3
