Chapter 11 Summary of Parameter SettingsME300
11-5
Pr. Explanation Settings Default
4: Pulse input without direction command
(refer to Pr.10-16 without considering direction)
7: Digital keypad potentiometer knob
9: PID controller (With Pr.08-65 = 1)
Note:
HOA (Hand-Off-Auto) function is valid only when you use with
MO function setting 42 and 56 or with KPC-CC01 (optional).
00-21
Operation command
source (AUTO, REMOTE)
0: Digital keypad
1: External terminals
2: RS-485 communication input
Note:
HOA (Hand-Off-Auto) function is valid only when you use with
MO function setting 42 and 56 or with KPC-CC01 (optional).
0
00-22 Stop method
0: Ramp to stop
1: Coast to stop
2: Motor stops by simple positioning
0
00-23 Motor direction control
0: Enable forward / reverse
1: Disable reverse
2: Disable forward
0
00-24
Digital operator (keypad)
frequency command
memory
Read only Read only
00-25
User-defined
characteristics
bit 0–3: user-defined decimal places
0000b–0000b: no decimal place
0001b–0001b: one decimal place
0010b–0010b: two decimal places
0011b–0011b: three decimal places
0
bit 4–15: user-defined unit
000xh: Hz
001xh: rpm
002xh: %
003xh: kg
004xh: m/s
005xh: kW
006xh: HP
007xh: ppm
008xh: 1/m
009xh: kg/s
00Axh: kg/m
00Bxh: kg/h
00Cxh: lb/s
00Dxh: lb/m
