Chapter 11 Summary of Parameter SettingsME300
11-9
Pr. Explanation Settings Default

01-19 Deceleration time 4
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00
10.0

01-20 JOG acceleration time
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00
10.0

01-21 JOG deceleration time
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
10.00
10.0

01-22 JOG frequency 0.00–599.00 Hz 6.00

01-23
Switch frequency
between first and fourth
acceleration /
deceleration
0.00–599.00 Hz 0.00

01-24
S-curve for acceleration
begin time 1
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20
0.2

01-25
S-curve for acceleration
arrival time 2
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20
0.2

01-26
S-curve for deceleration
begin time 1
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20
0.2

01-27
S-curve for deceleration
arrival time 2
Pr.01-45 = 0: 0.00–25.00 sec.
Pr.01-45 = 1: 0.0–250.0 sec.
0.20
0.2
01-28
Skip frequency 1
(upper limit)
0.00–599.00 Hz 0.00
01-29
Skip frequency 1
(lower limit)
0.00–599.00 Hz 0.00
01-30
Skip frequency 2
(upper limit)
0.00–599.00 Hz 0.00
01-31
Skip frequency 2
(lower limit)
0.00–599.00 Hz 0.00
01-32
Skip frequency 3
(upper limit)
0.00–599.00 Hz 0.00
01-33
Skip frequency 3
(lower limit)
0.00–599.00 Hz 0.00
01-34 Zero-speed mode
0: Output waiting
1: Zero-speed operation
2: Fmin (refer to Pr.01-07 and Pr.01-41)
0
01-35
Output rated / base
frequency of motor 2
0.00–599.00 Hz
60.00/
50.00
01-36
Output rated / base
voltage of motor 2
115 / 230V models: 0.0–255.0 V
460V models: 0.0–510.0 V
220.0
440.0
01-37
Mid-point frequency 1 of
motor 2
0.00–599.00 Hz 3.00
