Chapter 11 Summary of Parameter SettingsME300
11-17
Pr. Explanation Settings Default
5: DC bus voltage
6: Power factor
7: Power
9: AVI
12: Iq current command
13: Iq feedback value
14: Id current command
15: Id feedback value
16: Vq-axis voltage command
17: Vd-axis voltage command
21: RS-485 analog output
23: Constant voltage output

03-21 AFM Analog Output Gain 0.0–500.0% 100.0

03-22
AFM Analog Output in
REV Direction
0: Absolute value in output voltage
1: Reverse output 0 V; forward output 0
–10 V
2: Reverse output 5
–0 V; forward output 5–10 V
0

03-27 AFM output bias
-100.00
–100.00%
0.00

03-28
AI terminal input
selection
0: 0–10 V (Pr.03-63–03-68 is valid)
1: 0–20 mA (Pr.03-57–03-62 is valid)
2: 4–20 mA (Pr.03-57–03-62 is valid)
0

03-32
AFM DC output setting
level
0.00–100.00% 0.00

03-35 AFM output filter time 0.00–20.00 sec. 0.01

03-39 VR input selection
0: Disable
1: Frequency command
1

03-40 VR input bias -100.0–100.0% 0.0

03-41
VR positive / negative
bias
0: No bias
1: Lower than or equal to bias
2: Greater than or equal to bias
3: The absolute value of the bias voltage while serving
as the center
4: Bias serves as the center
0

03-42 VR gain -500.0–500.0% 100.0

03-43 VR filter time 0.00–2.00 sec. 0.01

03-44
Multi-function output
(MO) by AI level source
0: AVI
1: ACI
0

03-45 AI level 1 (upper limit)
-100.00
–100.00%
50.00

03-46 AI level 2 (lower limit)
-100.00
–100.00%
10.00
