Delta ME300 Series - Page 171

Chapter 11 Summary of Parameter SettingsME300
11-18
Pr. Explanation Settings Default

03-50
Analog input curve
selection
0: Normal curve
1: Three-point curve of AVI (& AI10)
2: Three-point curve of ACI (& AI11)
0

03-57 ACI lowest point
Pr.03-28 = 1, 0.00–10.00 V
Pr.03-28 ≠ 1, 0.00–20.00 mA
4.00

03-58
ACI proportional lowest
point
0.00–100.00% 0.00

03-59 ACI mid-point
Pr.03-28 = 1, 0.00–10.00 V
Pr.03-28 ≠ 1, 0.00–20.00 mA
12.00

03-60
ACI proportional mid-
point
0.00–100.00% 50.00

03-61 ACI highest point
Pr.03-28 = 1, 0.00–10.00 V
Pr.03-28 ≠
1, 0.00–20.00 mA
20.00

03-62
ACI proportional highest
point
0.00–100.00% 100.00

03-63 AVI voltage lowest point 0.00–10.00 V 0.00

03-64
AVI proportional lowest
point
-100.00–100.00% 0.00

03-65 AVI voltage mid-point 0.00–10.00 V 5.00

03-66
AVI proportional mid-
point
-100.00–100.00% 50.00

03-67 AVI voltage highest point 0.00–10.00 V 10.00

03-68
AVI proportional highest
point
-100.00–100.00% 100.00
